Nominal capacity

2700Ah

Nominal voltage

48V

Electricity(kWh)

135kWh

Inverter AC Output

Max power(kw)

54kW

Voltage(VAC)

360/380/397/415

Power factor(PF)

1

Frequency

50/60Hz±0.1%

Switch time(ms)

10(normal mode)/10(UPS mode)

Wave form

Pure sine wave

Overload capacity(battery mode)

60s@102%~110%load;10s@110%~130%load;
3s@130%~150%load;0.2s@>150%load

Max.Efficiency(battery mode)

93%@48VDC

Photovoltaic/AC Input

Rated input voltage(VAC)

360/380/397/415;U+V+W+N+PE

Phase voltage range(VAC)

90~280±3(normal mode);170~280±3(UPS mode)

Frequency(Hz)

50/60(auto adaptive)

Solar charger type

MPPT

Max PV input current/input power

18A/6000W×9

MPPT range@operating voltage per unit(VDC)

120~450

Max PV open circuit voltage perunit(VDC)

500

Max PV charge current perunit(A)

80

MaxAC charge current per unit(A)

80

Max.charge current per unit(PV+AC)(A)

80
