SMART-BCT-V-48-200/250/300(P)
1. Utilizing sunlight for clean energy charging, which can provide power to household appliances.
2. Excess solar energy is stored in batteries during the day and used at night, thus maximizing the utilization rate of solar energy.
3. Achieving electricity freedome in areas with no or limited power supply.
4. Using stored energy during blackout to keep appliances running.
Basic Specifications | |
Nominal Capacity | 200Ah/250Ah/300Ah |
Nominal Voltage | 48V(51.2V) |
Electricity(kWh) | 10.24kWh/12.8kWh/15.36kWh |
Rated Current | 100A |
Battery | |
Communication Interface | RS485/CAN |
Storage Temperature Range | -10℃-30℃ |
Operating Temperature Range | 0℃-50℃ |
Relative Humidity | 5-95%RH |
Atmospheric Pressure | Below the elevation of 5000m |
Self-Discharge(25℃) | <3%/month |
Depth of Discharge | >80% |
C-rate Discharge | <0.8C |
Cycle Life | >6000 times(<0.5C) |
Other | |
Certification Standards | UN38.3/CE/MSDS/DGM |
Package Size | 668(±2)X605(±2)X731(±2)mm |
Parallel | Up to 15 pcs |
